Technical Specification 14
Kwik Bay
Technical Specifi cation
5.1 Size And Main Features (Ref. Figure 2)
CAPACITY 7,000 LBS.
Max. lifting height 41” (With positioning blocks)
Min. lift height 4 ¼“
Length of the platform 57 ½” - 78” (4‘ 9 ½“ – 6‘ 6“)
Width of platform 19 ¼” (1’ 7 ¼”)
Free width between platforms 33 ½” (2’ 9 ½”)
Overall length 78 ½“ (6‘ 6 ½“)
Overall width 72” (6’)
Lifting time 35s
Lowering time 40s
Compressed air pressure 85-120 psi.
Noise level 80 dB(A)/1m
Working temperature 14 °F - 104 °F
Average weight of package 1,441 LBS.
5.2 Electric Motor
Type ML90L4-B14
Voltage 120V-1Ph (30 Amp Breaker Required)
Power 1.8 KW
N° Poles 4
Speed 1375 rpm
Motor enclosure type B14
Insulation class IP 54
Motor connection must be carried out referring to the attached wiring diagrams
(the fi gure. 5). The motor direction of rotation is shown in the label placed on
the motor. Before use of the lift, make sure to check if the motor specifi cation
shown in the nameplate of the motor conforms to the local electric supply. If
there is over 10% fl uctuation on the electrical power supply, it is suggested to
use the voltage stabilizer to protect the electrical components and system from
overloading.
