Parts List 35
Kwik Bay
Parts List
Lift
Item Part Number Description Qty
1 32MB00 Base 1
2 32ME00 Outer scissor 1
3 32MB04D Arm support D 2
4 0202059 Screw M10X50-GB/T70.1 12
5 32MB03B Arm support B 4
6 32MG30 Upper safety rack 2
7 32MW00 Wheel assembly 2
8 32MDC00 Table assembly 1
9 32MF00 Left inner scissor 1
10 33M-D210 Ramp 2 2
11 32MDC00 Table 1
12 YA20-0464 Guide roller 8
13 33M-D110 Ramp 1 2
14 32MDD30 Ramp locking plate 4
15 32ML12 Ramp shaft 8
16 0212001 Seeger D.12-GB/T894.1 16
17 32MF11 Nylon slider 4
18 32MF12 Spacer 2
19 32MG02 Lower safety rack 2
20 0215021 Greaser 8X1 8
21 0210016 Self-lubricated bush 3040 8
22 0212004 Seeger D.25-GB/T894.1 18
23 32ME13 Inner wheel 4
24 0210008 Self-lubricated bush 2520 12
25 0212021 Seeger D.30-GB/T894.1 4
26 0210039 Self-lubricated bush 2515 4
27 32ME12 Outer wheel 4
