Atlas Kwik Bay User Manual

Parts List 36
Kwik Bay
Item Part Number Description Qty
28 32MF00 Right inner scissor 1
29 32MC11 Upper shaft 4
30 32ME14 Upper wheel shaft 4
31 32ME11 Middle shaft 2
32 0206032 Screw M6X16-GB/T818 12
33 0306010 Safety air cylinder 32X23 2
34 0306046 Quick union 6-1/8 2
35 0209006 Screw M8X16-GB/T77 8
36 32MB12 Shaft 2
37 0207033 Screw M4X6-GB/T819.1 12
38 32MB11 Spacer 2
39 32MI14 Lower shaft 2
40 0210013 Self-lubricated bush 3024 4
41 32MI13 Wheel 2
42 32MI09 Upper shaft 2
43 32MI12 Bush 2
44 32ME15 Lower shaft 2
45 0210010 Self-lubricated bush 2530 2
46 32M-70-0 Hydraulic cylinder 2
47 0210070 Edged self-lubricated bush 3030 4
48 32MI00 Lifting lever 2
49 0505018 Limit switch 8108 (At Request) 1
50 0206026 Screw M5X16 2
51 32MW10 Wheel support 1
52 32MW21 Wheel 1
53 32MW22 Wheel shaft 1
54 0212005 Seeger D.20-GB/T894.1 2
