Operating manual SUNTEST XLS / XLS+
10
Maintenance
SUNTEST XLS / XLS+
Power supply:
Supply voltage: 200-240 V ± 10%, 50/60 Hz
Supply connection: CEE (32A, 3 pol., 6h) (1, N, PE)
Amperage: 20,5 A
Fuse rating: 32 A
Power consumption: max. 3.1 KW
Nominal rating of
Xenon-lamp: 2.2 kVA
Cooling requirement:
Lamp cooling: 250 m³/h
Air conditioner: 340 m³/h
Dimensions and weight:
Dimensions in mm: 930 x 500 x 485
(width x depth x height)
Sample table: 330 x 330 mm
Specimen surface area: about 1000 cm²
Weight: about 80 kg
Noise emission:
Noise level: < 75 dB(A)
Ambient conditions:
Room temperature: 18°C to 25°C
Relative humidity: max. 70%
Air pressure: 700 - 1060hPa
11
Technical data
10.1 Maintenance and care
At least once a year, it is necessary to ensure that the
following systems are in proper condition.
• Mechanical system
• Function (Technical Data)
• Electrical system (BRD: UVV VGB 4)
• Safety devices of the equipment
If protective devices have been dismantled or disabled
for
the sake of maintenance work, the equipment may be
started again only after the protective devices have been
installed again and their function has been checked.
NOTE - Guarantee:
The manufacturer guarantees the safety and proper
functioning of the equipment only provided that:
• the maintenance intervals are adhered to
• all maintenance work is carried out by trained and
suitably qualified personnel,
• only original spare parts are used.
ATLAS provides a customized service package for
this equipment, consisting of a maintenance service,
measurement and calibration service that ensures the
efficiency and process safety of the equipment.
10.2 Commissioning
NOTES - Spare parts:
We will provide a complete list of spare parts as well as
other documentation on request to suitably trained and
qualified personnel.
