176
8271D–AVR–05/11
ATmega48A/PA/88A/PA/168A/PA/328/P
• Bits 1, 0 – SPR1, SPR0: SPI Clock Rate Select 1 and 0
These two bits control the SCK rate of the device configured as a Master. SPR1 and SPR0 have
no effect on the Slave. The relationship between SCK and the Oscillator Clock frequency f
osc
is
shown in the following table:
19.5.2 SPSR – SPI Status Register
• Bit 7 – SPIF: SPI Interrupt Flag
When a serial transfer is complete, the SPIF Flag is set. An interrupt is generated if SPIE in
SPCR is set and global interrupts are enabled. If SS
is an input and is driven low when the SPI is
in Master mode, this will also set the SPIF Flag. SPIF is cleared by hardware when executing the
corresponding interrupt handling vector. Alternatively, the SPIF bit is cleared by first reading the
SPI Status Register with SPIF set, then accessing the SPI Data Register (SPDR).
• Bit 6 – WCOL: Write COLlision Flag
The WCOL bit is set if the SPI Data Register (SPDR) is written during a data transfer. The
WCOL bit (and the SPIF bit) are cleared by first reading the SPI Status Register with WCOL set,
and then accessing the SPI Data Register.
• Bit [5:1] – Reserved
These bits are reserved bits in the ATmega48A/PA/88A/PA/168A/PA/328/P and will always read
as zero.
• Bit 0 – SPI2X: Double SPI Speed Bit
When this bit is written logic one the SPI speed (SCK Frequency) will be doubled when the SPI
is in Master mode (see Table 19-5). This means that the minimum SCK period will be two CPU
clock periods. When the SPI is configured as Slave, the SPI is only guaranteed to work at f
osc
/4
or lower.
The SPI interface on the ATmega48A/PA/88A/PA/168A/PA/328/P is also used for program
memory and EEPROM downloading or uploading. See page 312 for serial programming and
verification.
Table 19-5. Relationship Between SCK and the Oscillator Frequency
SPI2X SPR1 SPR0 SCK Frequency
000
f
osc
/4
001
f
osc
/16
010f
osc
/64
011f
osc
/128
100
f
osc
/2
101f
osc
/8
110f
osc
/32
111
f
osc
/64
Bit 76543210
0x2D (0x4D) SPIF WCOL – – – – – SPI2X SPSR
Read/Write RRRRRRRR/W
Initial Value 0 0 0 0 0 0 0 0
