9.6 Calibrated Internal RC Oscillator
By default, the Internal RC Oscillator provides an approximate 8.0MHz clock. Though voltage
and temperature dependent, this clock can be very accurately calibrated by the user. See Table
29-10 on page 323 for more details. The device is shipped with the CKDIV8 Fuse programmed.
See ”System Clock Prescaler” on page 36 for more details.
This clock may be selected as the system clock by programming the CKSEL Fuses as shown in
Table 9-11. If selected, it will operate with no external components. During reset, hardware loads
the pre-programmed calibration value into the OSCCAL Register and thereby automatically cali-
brates the RC Oscillator. The accuracy of this calibration is shown as Factory calibration in Table
29-10 on page 323.
By changing the OSCCAL register from SW, see ”OSCCAL – Oscillator Calibration Register” on
page 38, it is possible to get a higher calibration accuracy than by using the factory calibration.
The accuracy of this calibration is shown as User calibration in Table 29-10 on page 323.
When this Oscillator is used as the chip clock, the Watchdog Oscillator will still be used for the
Watchdog Timer and for the Reset Time-out. For more information on the pre-programmed cali-
bration value, see the section ”Calibration Byte” on page 302.
Notes: 1. The device is shipped with this option selected.
2. If 8MHz frequency exceeds the specification of the device (depends on V
CC
), the CKDIV8
Fuse can be programmed in order to divide the internal frequency by 8.
When this Oscillator is selected, start-up times are determined by the SUT Fuses as shown in
Table 9-12.
Note: 1. If the RSTDISBL fuse is programmed, this start-up time will be increased to
14CK + 4.1ms to ensure programming mode can be entered.
2.
The device is shipped with this option selected.
Table 9-10. Start-up Times for the Low-frequency Crystal Oscillator Clock Selection
CKSEL3...
0
Start-up Time from
Power-down and Power-save Recommended Usage
0100
(1)
1K CK
0101 32K CK Stable frequency at start-up
Table 9-11. Internal Calibrated RC Oscillator Operating Modes
Frequency Range
(2)
(MHz) CKSEL3...0
7.3 - 8.1 0010
(1)
Table 9-12. Start-up times for the internal calibrated RC Oscillator clock selection
Power Conditions
Start-up Time from Power-
down and Power-save
Additional Delay from
Reset (V
CC
= 5.0V) SUT1...0
BOD enabled 6 CK 14CK
(1)
00
Fast rising power 6 CK 14CK + 4.1ms 01
Slowly rising power 6 CK 14CK + 65ms
(2)
10
Reserved 11
