247
8271D–AVR–05/11
ATmega48A/PA/88A/PA/168A/PA/328/P
Figure 22-22.
TWI Address Match Logic, Block Diagram
•
Bit 0 – Reserved
This bit is an unused bit in the ATmega48
A/PA/88A/PA/168A/PA/
328/P, and will always read as
zero.
Address
Match
Address Bit Comparator 0
Address Bit Comparator 6..1
TW
AR0
TW
AMR0
Address
Bit 0
