ATmega48A/PA/88A/PA/168A/PA/328/P
Figure 30-66. ATmega48PA: Reset Pull-up Resistor Current vs. Reset Pin Voltage (V
CC
= 2.7 V)
Figure 30-67. ATmega48PA: Reset Pull-up Resistor Current vs. Reset Pin Voltage (V
CC
= 5 V)
85 °C
25 °C
-40 °C
0
10
20
30
40
50
60
0 0.5 1 1.5 2 2.5 3
V
RESET
(V)
I
RESET
(uA)
85 °C
25 °C
-40 °C
0
20
40
60
80
100
120
0 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5
V
RESET
(V)
I
RESET
(uA)
