Figure 30-70. ATmega48PA: I/O Pin Output Voltage vs. Source Current (Vcc = 3 V)
Figure 30-71. ATmega48PA: I/O Pin Output Voltage vs. Source Current (V
CC
= 5 V)
85 °C
25 °C
-40 °C
0
0.5
1
1.5
2
2.5
3
3.5
048 12 16 20
I
OH
(mA)
V
OH
(V)
85 °C
25 °C
-40 °C
4.2
4.3
4.4
4.5
4.6
4.7
4.8
4.9
5
048 12 16 20
I
OH
(mA)
V
OH
(V)
