Figure 30-237.ATmega168PA: Active Supply Current vs. Frequency (1-20MHz)
Figure 30-238.ATmega168PA: Active Supply Current vs. V
CC
(Internal RC Oscillator, 128kHz)
5.5 V
5.0 V
4.5 V
0
2
4
6
8
10
12
02468 10 12 14 16 18 20
Frequency (MHz)
I
CC
(mA)
1.8 V
4.0 V
3.3 V
2.7 V
85 °C
25 °C
-40 °C
0
0.03
0.06
0.09
0.12
0.15
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(mA)
