Figure 49. I/O Pin Source Current vs. Output Voltage
Figure 50. I/O Pin Input Threshold Voltage vs. V
CC
0
1
2
3
4
5
6
0 0.5 1 1.5 2 2.5 3
I/O PIN SOURCE CURRENT vs. OUTPUT VOLTAGE
I (mA)
OH
V (V)
OH
T = 85˚C
A
T = 25˚C
A
V = 2.7V
cc
0
0.5
1
1.5
2
2.5
2.7 4.0 5.0
Threshold Voltage (V)
V
cc
I/O PIN INPUT THRESHOLD VOLTAGE vs. V
cc
T = 25˚C
A
