Table 4-28 GPIO Lines Connected to the EDBG
SAM E70 Pin Function Shared Functionality
PA9 DGI_GPIO0 Camera Connector, Embedded Debugger
PA23 DGI_GPIO1 J507 Header, Embedded Debugger
PD28 DGI_GPIO2 EXT1 Header, Camera Connector,J503 Header, J505 Header, Embedded
Debugger
PA2 DGI_GPIO3 EXT2 Header, J503 Header, Embedded Debugger
Atmel SAME70-XPLD [USER GUIDE]
Atmel-44050A-SAME70-XPLD_User Guide-12/2015
