Table 4-24 SWD Connections
SAM E70 Pin Function Shared Functionality
PB5 SWO Trace Data Trace Connector (J403), Embedded Debugger
PB6 SWD Data Trace Connector (J403), Embedded Debugger
PB7 SWD Clock Trace Connector (J403), Embedded Debugger
PB12 Erase Embedded Debugger
4.6.2. Virtual COM Port
The Embedded Debugger acts as a Virtual Com Port gateway by using one of the ATSAME70Q21
UARTs. For further information on how to use the Virtual COM port, see Embedded Debugger on page 7.
Table 4-25 Virtual COM Port Connections
SAM E70 Pin Function Shared Functionality
PB4 TXD1 (SAM E70 UART TX Line) EXT2 Header, J507 Header, Embedded Debugger
PA21 RXD1 (SAM E70 UART RX Line) EXT2 Header, J507 Header, Embedded Debugger
4.6.3. Atmel Data Gateway Interface
The Embedded Debugger features an Atmel Data Gateway Interface (DGI) by using either a SPI or I
2
C
port. The DGI can be used to send a variety of data from the ATSAME70Q21 to the host PC. For further
information on how to use the DGI interface, see Embedded Debugger on page 7.
Table 4-26 DGI Interface Connections When Using SPI
SAM E70 Pin Function Shared Functionality
PD12 SPI0_NPCS2 (Slave Select) Camera Connector, Embedded Debugger
PD20 SPI0_MISO (Master In, Slave
Out)
EXT1 Header, EXT2 Header, J500 Header, J506
Header, Embedded Debugger
PD21 SPI0_MOSI (Master Out -
Slave In)
EXT1 Header, EXT2 Header, J500 Header, J506
Header, Camera Connector, Embedded Debugger
PD22 SPI0_SPCK EXT1 Header, EXT2 Header, J500 Header, J506
Header, Camera Connector, Embedded Debugger
Table 4-27 DGI Interface Connections When Using I²C
SAM E70 Pin Function Shared Functionality
PA3 TWD0 (I²C Data Line) EXT1 Header, EXT2 Header, J500 Header, AT24MAC402,
Camera Connector, Embedded Debugger
PA4 TWCK0 (I²C Clock Line) EXT1 Header, EXT2 Header, J500 Header, Camera
Connector, Camera Connector, Embedded Debugger
Four GPIO lines are connected to the Embedded Debugger. The EDBG can monitor these lines and
timestamp pin value changes. This makes it possible to accurately timestamp events in the SAM E70
application code. For further information on how to configure and use the GPIO monitoring features, see
Embedded Debugger on page 7.
Atmel SAME70-XPLD [USER GUIDE]
Atmel-44050A-SAME70-XPLD_User Guide-12/2015
42
