3-7
3. Mount the IR-450 on the Picatinny Adapter and tighten the
fixing screw.
G. MOUNTING CAMERA/CAMCORDER TO THE
1. Screw Camera Adapter into the front lens of a photographic
camera with thread M52x0.75 (Figure 3.7) or a video camera
with thread M37x0.75 (use adapter ring, Figure 3.8, B) .
2. Remove the rubber eyecup off the monocular.
B
A
C
A
B
