ii
LIST OF FIGURES
FIGURE TITLE PAGE
1.1 Multi-Use Night Vision monocular 1-2
2.1 ATN NVM-14 Kit Components 2-4
2.2 ATN NVM-14 Optional Components 2-4
3.1 Attaching ATN NVM-14 to Head Mount 3-2
3.2 Attaching ATN NVM-14 to Helmet Mount 3-3
3.3 3-4
3.4 Mounting the ATN NVM-14 to a Scope 3-5
3.5 Mounting of the Dual Bridge Adapter 3-6
3.6 Mounting the Picatinny Adapter to the ATN NVM-14 3-7
3.7 Mounting camera to the ATN NVM-14 3-7
3.8 Mounting camcorder to the ATN NVM-14 3-8
3.9 Attaching Adapter to ATN NVM-14 3-8
3.10 Attaching ATN NVM-14 to Mil-Spec Headmount 3-9
3.11
Pair of ATN NVM-14 with Dual Bridge Adapter on the
Mil-Spec Headmount
3-9
3.12 Mounting 3x and 5x Lens to the ATN NVM-14 3-10
3.13 Mounting Bi-ocular to the ATN NVM-14 3-10
4.1 CR123A Battery Installation 4-3
4.2 AA Battery Installation 4-3
4.3 Mechanical Functions 4-4
4.4 Infrared (IR) Illuminator Operations 4-5
5.1 Shading 5-2
5.2 Edge Glow 5-3
5.3 Bright Spots and Emission Points 5-4
5.4 Fixed Pattern Noise 5-5
5.5 5-6
6.1 Removal and Installation of Browpad 6-9
6.2 Removal and Installation of Chinstrap 6-9
6.3 Removal and Installation of Chin Cup 6-10
6.4 Maintenance / Replacement of the tube in the NVM-14 6 -11
6.5 Purge System 6-12
