ATN Zebra 12 User Manual

OPERATOR’S AND SAFETY HANDBOOK
1NO0060EN-00
Zebra 12 – Zebra 16
87
Pressure in the circuit of the elevation movement pilot block in bars.
Condition of the structure sensors Arm 1 / Arm 2 / Telescope.
When the machine is lowered, the 3 indicators must be lit in green.
Info Engine start button.
Info enable button lower control box.
Info engine running (sensor RPM info).
Tilt, lit green if ok and red if beyond or disconnected.
Overload, lit red if active.

ATN Zebra 12 Specifications

General

Brand	ATN
Model	Zebra 12
Category	Boom Lifts
Language	English
