alldimensionsininchesunlessotherwisenoted[alldimensionsinbracketsareinmillimeters]
UPS Series
basic dimensions
UPS-1000R Series UPS-2200R Series
Input
Nominal Input Voltage 120 V 120 V
Input Voltage Range 80VAC – 145VAC 80VAC – 145VAC
Input Frequency 60 Hz +/- 3 Hz (auto sensing) 60 Hz +/- 3 Hz (auto sensing)
Input Protection Type Resettable thermal fuse Resettable thermal fuse
Cord Length / Cord Type / Plug Type 9 ft. / 14/3 / NEMA 5-15P 9 ft. / 12/3 / NEMA 5-20P
Output
Green Mode Consumption Less than 9W at full battery capacity Less than 9W at full battery capacity
Nominal Output Voltage 120 V 120 V
Capacity (VA) 1000VA 2150VA
Capacity (Watts) 750W 1650W
Waveform Pure Sine Wave Pure Sine Wave
On Line Output Frequency 57 - 63 Hz for 60 Hz nominal 57 - 63 Hz for 60 Hz nominal
On Battery Output Frequency 60 Hz +/- .1 Hz 60 Hz +/- .1 Hz
Transfer Time (Typical) 4 ms typical line to battery / battery to line 4 ms typical line to battery / battery to line
Overload Protection
(on line mode)
100%
<
Load< 110% warning, 120 sec shutdown
110%
<
Load< 125% warning, 40 sec shutdown
125%
<
Load warning, 10 sec shutdown
100%
<
Load< 110% warning, 120 sec shutdown
110%
<
Load< 125% warning, 40 sec shutdown
125%
<
Load warning, 10 sec shutdown
Overload Protection
(on battery mode)
100%
<
Load< 110% warning, 30 sec shutdown
110%
<
Load< 125% warning, 10 sec shutdown
125%
<
Load warning, 3 sec shutdown
100%
<
Load< 110% warning, 30 sec shutdown
110%
<
Load< 125% warning, 10 sec shutdown
125%
<
Load warning, 3 sec shutdown
Total Harmonic
Distortion (THD)
*typical 120V power
with 2%-4% THD
Total System Load 0% 20% 60% 100%
Utility Mains* THD 2.0% 2.0% 2.0% 2.0%
Battery Backup THD 1.9% 1.3% 1.5% 5.2%
Surge Protection
& Filtering
Lightning / Surge Protection
L-N=>381 J (127J x 3) Clamp voltage 270V
(Max energy 10 / 1000 µs)
L-N=>381 J (127J x 3) Clamp voltage 270V
(Max energy 10 / 1000 µs)
RJ11 / RJ45 Protection
Sidactorx1 Clamp Voltage 275V
Fuse (.75A / 250V) x 2
Sidactorx1 Clamp Voltage 275V
Fuse (.75A / 250V) x 2
Physical
Output Receptacles (8) NEMA 5-15R (8) NEMA 5-20R
Dimensions (in.) 19.00” [423] W x 3.50” [89] H x 19.29” [490] D 19.00” [423] W x 3.50” [89] H x 19.29” [490] D
Weight (lb.) 68 lbs. 77 lbs.
Battery
Rating 12V / 9.0 AH x 4 12V / 9.0 AH x 4
Auto Charger 1A 1A
Hot Swappable External Battery Ye s Yes
Run Time at Half Load 26 minutes 13 minutes
Run Time at Full Load 13 minutes 6.4 minutes
Warning
Diagnostics
Control Panel LCD Display Indicators, Power On LCD Display Indicators, Power On
Audible Alarms On Battery, Low Battery On Battery, Low Battery
Environmental
Operating Temperature 32°F to 104°F ( 0°C to 40°C) 32°F to 104°F ( 0°C to 40°C)
Operating Relative Humidity 0 to 95% Non-Condensing 0 to 95% Non-Condensing
