All-in-one wall panel
The MWX65 is an All-in-one wall panel designed for use in combination with AUDAC MTX series
matrix systems. This wall panel has a graphic display and can control the routing, volume, bass,
treble and mute for one zone. Besides those control functions, it also provides the possibility to
connect a microphone and a stereo line input source. The MWX65 wall panel should be connected
using UTP/FTP CAT5E (or better) twisted pair cabling.
The following functions of the zone can be controlled:
- Volume within a range of 0dB to -70 dB
- Input source selection
- Mute / unmute
- Bass within a range of -14dB to +14dB
- Treble within a range og -14dB to +14dB
The microphone input on the wall panel is connected using an XLR connector, while the line
inputs are implemented using RCA connectors.
