Installing, connecting & configuring
Installing
Different kinds of installation boxes are available for the MWX65, making both flush and surface
mount installation possible on different kinds of surfaces. The WB50/FG installation box allows flush
mount installation in any kind of hollow wall such as gypsum, wood or any other material with a plate
thickness between 7 mm and 25 mm. The WB50/FS installation box allows flush mount installation
through mortar in stone or concrete surfaces. For surface mount installation, wall boxes WB50/B and
WB50/W are available.
The wall panel should be fixed into the installation box by tightening the included screws.
