Audi A6 2005 - Electrics - High Variant ECE Back Lights

38
High variant ECE
These back lights are installed if bi-xenon headlights
at least are fitted as the front headlights.
The external feature of the High back lights is the
use of LEDs for the brake light.
The LEDs, which are fixed in the reflector housing,
are activated by two contacts from the lamp
bracket.
The rear fog light is located at the bottom of the
back light. Here, the lamp on the driver’s side is
used as the rear fog light, while the lamp on the
passenger’s side serves as the reversing light.
This means that the same lamp bracket can be used
for both the High back light and the Basic back light.
Convenience electrics
326_152
Direction
indicator light
Rear fog light
Brake light
Tail lights
Direction
indicator
light
Reversing light
Brake light
Tail lights
