Audi A6 2005 - Electrics - Antenna Systems

75
Antenna systems
The antenna system in the new Audi A6 ´05 is
integrated as a module in the top area of the rear
window, to the left and next to the third brake light,
on the right.
The modules are responsible for the various
systems, e.g. remote central locking, radio, TV or the
radio receiver for the auxiliary heater.
Only the modules that are required for the
requested optional extras are installed.
The table shows the relevant modules for the
available vehicle equipment. These are indicated for
the various, worldwide country versions.
The modules "DAB" and "SDARS" relate to the digital
radio systems, which will be available later and are
based on either a satellite-controlled system
(SDARS) or a terrestrial system (DAB).
Module Designation Available in market version
1
1
1
1
2
4
2
2
2
3
4
5
5
5
5
7
8
Radio AM/FM
Radio AM/FM-Diversity
Radio AM/FM-Div/TV
Radio AM/FM-Div/TV
Remote central locking
Remote control for auxiliary heater
Remote locking/TV
Remote locking/TV/DAB
Remote central locking/TV
Navigation
Mobile phone-US
Tele p h o n e ECE
Telephone (fixed or mobile)/Navigation
Telephone/Navigation
Satellite radio
Block circuit
Tele p ass
ECE
ECE/US
ECE/US
Japan
ECE/US
ECE
ECE/US
ECE
Japan
RoW
US
ECE
ECE
US
US
Italy
Installed antenna modules for possible vehicle equipment
Module 1
Module 3 Module 4
Module 2
Module 5
Module 7
Module 6
A
M
/
F
M
-
D
i
v
/
T
V
1-
2
Third brake light
T
V
3
-
4
/
R
e
m
o
t
e
c
e
n
t
r
a
l
l
o
c
k
i
n
g
/
R
C
/
D
A
B
326_125
Module 1: Radio/antenna amplifier R24
Module 2: Remote central locking/antenna amplifier 2 R111
Module 3: GPS/antenna for GPS navigation R50
Module 4: Mobile phone antenna USA/Antenna for telephone,
navigation, auxiliary heater R66
Module 5: Roof antenna/antenna for radio, telephone,
navigation R52
Module 6: Block circuit
Module 7: Telepass antenna
