79
Overview of the measured-value blocks available
for the individual modules
Module Designation
General measured-value blocks
for all modules
General: Battery positive voltage, terminal status
MOST: Address, MOST FOT temperature, optical lowering
Status of ring break diagnosis line
Control unit identification:
Serial number, flash date, hardware and software version
Control unit for front information
J523
Multimedia operating unit E380: Status of main buttons, status of knobs/pushbuttons,
volume controller status
Display: LCD display temperature
Signals: Terminal 58D, terminal 58S
Integrated amplifier,
2x20-watt
Status of input signals, status of mute lead, speed (GALA), temperature
Radio R Remote-feed antenna: Open circuit, OK, short circuit
Remote-feed ZF output: Open circuit, OK, short circuit
Transmitter receive-level (0... 100 dBµV)
CD ROM drive R92 CD status: Button status (Play, Stop, etc.), Eject button status, status of functions (Repeat, Scan, etc.)
Control unit for navigation
with CD drive J401
Route Info: Speed, direction of travel
GPS: Satellites received, status of remote-feed GPS antenna OK, short circuit, open circuit
GPS FIX: GPS information on satellite reception and position-finding
Drive: Status of CD drive, incorrect or no navigation CD inserted, Load Eject error,
CD drive overheating
Status of navigation CD
Longitude corrected: Arc degree, arc minute, arc second
Latitude corrected: Degree of longitude, minute of longitude, second of longitude
Height and angle of direction corrected: Height in metres, angle of direction in degrees
GPS date: Day, month, year or "invalid" if there is no GPS reception
GPS time: Hour, minute, second or "invalid" if there is no GPS reception
Front axle distance pulses, status
GPS level 1: Satellite ID with best and second-best reception
GPS level 2: Satellite ID with third-best reception
