Measured-value block Designation
01 General: Battery positive voltage
02 MOST: MOST address, FOT temperature
03 Status of ring break diagnosis line
04 System: Analogue/digital unit temperatures in amplifier, fan speed
05 Microphone: Microphone voltage(s) for AudioPilot microphone and optical microphone
for voice operating system
50 Control unit identification: Manufacturer code
51 Control unit identification: Serial number
No. Brief description and designation
of the component to be tested
Actuator diagnosis
Sequential Selective
1 R21 Low-pitch loudspeaker, front left X X
2 R23 Low-pitch loudspeaker, front right X X
3 R20 High-pitch loudspeaker, front left X X
4 R22 High-pitch loudspeaker, front right X X
5 R14 High-pitch loudspeaker, rear left X X
6 R16 High-pitch loudspeaker, rear right X X
7 R103 Middle-pitch loudspeaker, front left X X
8 R104 Middle-pitch loudspeaker, front right X X
9 R158 Centre loudspeaker X X
10 R150 Loudspeaker in parcel shelf X X
11 R159 Mid/low-pitch loudspeaker, rear left X X
12 R160 Mid/low-pitch loudspeaker, rear right X X
13 Fan in control unit X
14 J525 Self-test for digital sound package control unit X
Available actuator tests
