For example, the symbol II appears in the
display, indicating low windshield washer flu-
id level. The fo llowing message also appears:
Please refill washer fluid
The driver message disappears after a few
seconds. The driver message can be d isp layed
again by briefly pressing the
!CHECK I button.
Red symbols
Fig. 25 Display: engine coolant level warning (priority
1)
With a priority 1 malfunction, a large symbol
appears in the center area of the display
¢ fig . 25 . Wh en the symbo l appears, three
warning tones sound in succession. The sym-
bol continues to blink until the malfunct ion
has been repaired.
If there are
more than one priority 1 ma lfunc-
tions, the symbols appear one after the other
for about 2 seconds.
An additional driver message can also be dis-
played by briefly pressing the
I CHECK ! button .
The red symbols mean:
Alternator malfunct ion
¢page31
USA models: Brake system
malfunction
¢page32
Canada models: Brake sys-
tem malfunction
¢pa ge32
Engine coolant level too
low/engine coolant temper-
ature too high
¢ page32
Driver information display 31
@ Tips
Engine o il pressure too low
¢p age 33
Refill Ad Blue*
¢page 252
AdBlue malfunct ion*
c!>page252
Faulty steering
c!>page 33
Faulty ignition switch
¢page 33
- If the warning/indicator light 11111 (USA
models)/ . (Cana da models) in the in-
strument cluste r flashes, there is a brake
system malfunction. By pressing the
!CHECK I button, you can bring up a driver
message which exp lains the malfunction
in more detail. Please note ¢
page 32.
- Speed warnings threshold 1 . (USA
mode ls)/ . (Canada models) and
threshold 2 . (USA models) . (Cana-
da models) are also shown as red sym-
bols. The warning is always shown as a
small symbol in the uppe r area of the
display c!> page 28.
0 Alternator malfunction
If the . symbol in the instrument pane l dis-
play flashes, then there is a malfunction in the
alternator or the vehicle elect ronics. A warn-
ing to the driver will appear, too . The driver
warning goes out after about 5 seconds, but it
can be brought up at any time by pressing the
ICHECK I button aga in.
Usually, you can still drive to the next deale r-
ship . Turn off all but the most necessary elec-
trical consumers, since these drain the vehi-
cle's battery.
([) Note
If the . wa rning symbo l (coolant system
malfunction) also lights up on the instru-
ment panel during the trip¢
page 32,
then you have to stop immediately and ..,_
