Audio Precision 2700 Series User Manual

Digital Signal Generator
Available only in the SYS-2720 and SYS-2722 configurations. The 2700 series
digital generator consists of a DSP signal generator, hardware impairment generators
and processing (for example, variable risetime and induced jitter), and digital output
stages supporting the most popular formats.
Except for arbitrary and Pass Thru waveforms, the embedded output signals and the
digitally generated analog output signals are independently selectable and concurrently
available. If both digital and analog outputs are selecting arbitrary waveform, it must
be the same one. If Pass Thru waveforms are selected for both analog and digital
generators, they must be at the same sample rate.
Interface Signal Characteristics
Output Formats Balanced XLR (AES/EBU per AES3-r1997),
Dual Connector XLR,
Unbalanced BNC (SPDIF-EIAJ per IEC-60958),
Dual Connector BNC,
Optical (Toslink
®
) per IEC-60958,
General purpose parallel, or
Serial interface to chip via optional PSIA-2722.
Sam ple Rate (“SR”)
Range 28 kHz–200 kHz for fully specified performance.
Usable from 16 kHz–216 kHz.
Res o lu tion <0.0001 Hz.
Ac cu racy ±0.0002% [±2 PPM],
lockable to external reference.
Out put Am pli tude
Bal anced (XLR)
Range 0 Vpp–10.20 Vpp into 110 W.
Out put is un spec i fied above 8.00 Vpp if
SR >108 kHz.
Res o lu tion 40 mV, 4 mV be low 1 Vpp.
Ac cu racy ±(10% + 80 mV).
Unbal anced (BNC)
Range 0 Vpp–2.55 Vpp into 75 W.
Out put is un spec i fied above 2.00 Vpp if
SR >108 kHz.
Res o lu tion 10 mV, 1 mV be low 0.25 Vpp.
Ac cu racy ±(8% + 20 mV).
Op ti cal Fixed using Toslink® TOTX142L.
Out put im ped ance
Bal anced (XLR) Nom i nally 110 W.
Un bal anced (BNC) Nom i nally 75 W.
Chan nel Sta tus Bits Full im ple men ta tion per IEC 60958, Eng lish
lan guage de coded, Pro fes sional or con sumer or
hex for mats; in de pend ent in each chan nel.
User Bits Set to 0.
Va lid ity Flag Selectable-set or cleared, com mon to both
outputs.
Digital Signal Generator Chapter 6: Specifications
Getting Started with Your 2700 Series Instrument 75
