Audio Technica AT-LPW50PB User Manual

3
Notes on use
Turntable body
• Do not set and use the product in locations that are considerably hot
or humid, dirty, or subject to extreme vibrations.
• The product should be positioned on a flat, level surface.
• When closing the dust cover, close it completely.
Cartridge
• Attach the provided protector to the cartridge when the product is
not in use.
• Do not touch the stylus of the cartridge with your finger.
• Do not allow the stylus to bump against the platter, rubber mat, or
edge of the record.

Audio Technica AT-LPW50PB Specifications

Turntable Specifications

type	Belt-drive manual turntable
motor	DC servo with Active Speed Stabilization
drive method	Belt drive
speeds	33-1/3 RPM, 45 RPM
turntable platter	Aluminum Die Casting

Tonearm Specifications

type	Static balanced straight carbon tonearm
effective length	223.6 mm
overhang	18.6 mm
maximum tracking error angle	Less than 2.0°
stylus pressure adjustment	0 to 3.0 g range

Cartridge and Headshell Specifications

cartridge model	AT-VM95E BK
cartridge type	VM
recommended load	47, 000 ohms impedance
output voltage	4.0 mV
tracking force range	1.8 to 2.2 g

General Specifications

power supply requirements	100 to 240 V, 50/60 Hz, 0.5 A Max.
power consumption	1.3 W
ac adapter	12 V, 0.5 A
dimensions	420 mm × 340 mm × 126 mm
weight	5.56 kg
