Audio Technica AT2020USB-X User Manual

43
2
In the "Privacy" tab, select "Microphone".
3
Check that the recording software you are using is enabled.
• If it is not enabled, select the check box next to this software.
• To change the "Security & Privacy" settings, you have to unlock them with the icon in the lower-left corner of
the screen. Clicking this icon displays a screen for unlocking the settings. Enter the user name and password,
and then click "Unlock". After changing the settings, lock them.

Audio Technica AT2020USB-X Specifications

General

Cable length	2 m
Control type	Buttons, Rotary
Plug and Play	Yes
Product color	Black
Windows operating systems supported	Windows 10, Windows 11, Windows 8.1
Power source	USB
Input voltage	5 V
Device interface	3.5 mm (1/8\
USB connector type	USB Type-C
Connectivity technology	Wired
Cables included	USB Type-C to USB Type-A
Number of products included	1 pc(s)
Type	PC microphone
Bit rate	24 bit
Sample rate	96 kHz
Volume control	Rotary
Voice coil type	Dynamic
Microphone frequency	20 - 20000 Hz
Microphone Total Harmonic Distortion (THD)	1 %
Output impedance	32 Ω

Weight and Dimensions

Height	142 mm
Diameter	52 mm
Microphone weight	373 g
