Audio Technica AT2020USB-X User Manual

44
Audio device settings
To change the sample rate of the microphone and the levels of the left and right input signals, configure the following
settings.
1
Open "Audio Midi Setup" in the "Utilities" folder in the "Applications" folder.
2
Under "Audio Devices", select the product. In the "Input" tab, select the sample rate and bit depth from "Format".
• Two types of the product are displayed, but select the one that shows "1 in / 0 outs".
• With this product, you can select a sample rate of up to 96 kHz. Selecting a high sample rate may result in high-
quality recorded audio data but will also make these files large.
• For stable recording with less load on the computer, change the sample rate to 48 kHz.
• Match the sample rate to the value set with the recording software. Failing to do so may result in noise.

Audio Technica AT2020USB-X Specifications

General

Cable length	2 m
Control type	Buttons, Rotary
Plug and Play	Yes
Product color	Black
Windows operating systems supported	Windows 10, Windows 11, Windows 8.1
Power source	USB
Input voltage	5 V
Device interface	3.5 mm (1/8\
USB connector type	USB Type-C
Connectivity technology	Wired
Cables included	USB Type-C to USB Type-A
Number of products included	1 pc(s)
Type	PC microphone
Bit rate	24 bit
Sample rate	96 kHz
Volume control	Rotary
Voice coil type	Dynamic
Microphone frequency	20 - 20000 Hz
Microphone Total Harmonic Distortion (THD)	1 %
Output impedance	32 Ω

Weight and Dimensions

Height	142 mm
Diameter	52 mm
Microphone weight	373 g
