AudioArts Engineering R-55 - Page 60

W#
ITEM#
QTYDESCRIPTION
SL-55 STEREO LINE INPUT MODULE PARTS LIST
510097SW2-SW7 62 POLE PUSHBUTTON SWITCH, ALTERNATE ACTION
510282SW1 17 POSITION RIGHT ANGLE DIP SWITCH
520051FADER KNOB 1WHITE FADER KNOB WITH BLACK LINE
530057START SWITCH BUTTON 1LB STYLE RED BUTTON
530060STOP SWITCH BUTTON 1LB STYLE YELLOW BUTTON
530083
A/B/PGM/AUD/MONO/PRE/CUE SWITCH
BUTTON
6CUSTOM WHITE LIGHT PIPE BUTTON
540028FADER 1
10K DUAL AUDIO TAPER SELMARK CARBON FADER
100mm
600027START SWITCH LED 1RED LED FOR R5 ON/OFF SWITCH
600031STOP SWITCH LED 1YELLOW LED FOR R5 ON/OFF SWITCH
605010DS1 1HIGH INTENSITY AMBER SMT LED RIGHT ANGLE
605017DS2, DS6 2ULTRABRIGHT RIGHT ANGLE RED SMT LED
605018DS3 1ULTRABRIGHT RIGHT ANGLE GREEN SMT LED
605019DS4, DS5 2ULTRABRIGHT RIGHT ANGLE YELLOW SMT LED
700656PCB_SL2000 1PRINTED CIRCUIT BOARD SMT
8200472D SUB STANDOFFJACK HARDWARE 3/16" LONG
8210094PEM FASTENERS
835001F1-F3 3FUSE/ POLYSWITCH .3AMP SMT RESETABLE
page 10 - 3
R-55 / Aug 2003
