AudioArts Engineering R-55 - Control Room;Studio

W#
ITEM#
QTYDESCRIPTION
CRS-55 CONTROL ROOM/STUDIO MODULE PARTS LIST
005525CRS-55 1FACEPLATE
220120CT1 1RIGHT ANGLE 25 PIN PC MOUNT CONNECTOR .318
23002813 PIN .098" PLUG FOR #26 AWG
23003136 PIN .098" PLUG FOR #26 AWG
250062CT3 13 PIN .098" HEADER
250065CT5-CT7 36 PIN .098" HEADER
305021U8, U25, U26 3
74ACT74 TTL SMT Dual D-Type Pos-Edge-Triggered
Flip-Flop
320007U20-U22 3LM675 POWER OP AMP
325002U1, U4-U7, U12, U23, U24 8OP-275 DUAL LINEAR OP-AMP SMT
345002Q1 1MMBTA55 PNP SMT TRANSISTOR
350013Z3 16.2V 1W ZENER DIODE
355001D1, D2 21N4002W RECTIFYING 1AMP SMT DIODE
355002Z1, Z2 25.1V SMT ZENER DIODE C5V1
355003D4 11N4148 FAST SWITCHING SMT DIODE
355004D3 1SS14 SCHOTTKY SMT DIODE
385000U13-U19 74053 SMT
405002
C1-C3, C19, C20, C22-C28, C32, C33, C47, C48,
C50, C65-C68, C97-C99, C102, C105
26CAPACITOR, 22µF 25V ELECTROLYTIC SMT
405002C109-C112 4CAPACITOR, 22µF 25V ELECTROLYTIC SMT
405003C29, C30, C95, C96, C101 5CAPACITOR, 100µF 25V ELECTROLYTIC SMT
405004C49, C53 2CAPACITOR, 330µF 25V ELECTROLYTIC SMT
405005C69, C71, C73, C83, C86, C89 6CAPACITOR, 1µF 35V ELECTROLYTIC SMT TANTALUM
415001
C4, C11, C13, C14, C16, C34, C36, C41, C43-C45,
C51, C63, C82, C93, C94, C106, C108
18CAPACITOR, 10pF 100V CERAMIC SMT
415002C70, C72, C74 3CAPACITOR, 33pF 100V CERAMIC SMT
415004C85, C88, C91 3CAPACITOR, 330pF 100V CERAMIC SMT
415007
C5, C8, C10, C12, C15, C17, C18, C35, C37, C38,
C40, C42, C46, C52, C54, C55, C57, C60
18CAPACITOR, .1µF 50V CERAMIC SMT
415007
C62, C64, C76, C79, C81, C92, C100, C103, C104,
C107
10CAPACITOR, .1µF 50V CERAMIC SMT
415009C84, C87, C90 3CAPACITOR, .22µF 50V CERAMIC SMT
435001R147-R152 63.3 OHM 5% .25W MC1206 RESISTOR
435002
R6, R14, R20, R27, R42, R44, R54, R56, R58,R60,
R68, R70, R118, R119, R156, R157, R160, R161
1810 OHM 5% .25W MC1206 RESISTOR
435005F1, F5, F6 347 OHM 5% .25W MC1206 RESISTOR
435007R3, R4, R7, R12, R16-R18, R21, R46, R62 10100 OHM 5% .25W MC1206 RESISTOR
435008R37 1150 OHM 5% .25W MC1206 RESISTOR
435009R28, R36, R38, R39 4220 OHM 5% .25W MC1206 RESISTOR
435015R123, R126, R128 31.00 KOHM 1% .25W MC1206 RESISTOR
435017R32, R87, R98, R174, R194 51.69 KOHM 1% .25W MC1206 RESISTOR
435018R40, R72, R188, R189 42.00 KOHM 1% .25W MC1206 RESISTOR
page 10 - 6
R-55 / Mar 2003
