AudioArts Engineering R-55 - Page 64

W#
ITEM#
QTYDESCRIPTION
CRS-55 CONTROL ROOM/STUDIO MODULE PARTS LIST
435020R74, R120 22.43 KOHM 1% .25W MC1206 RESISTOR
435021R90, R92, R94, R162, R164, R166, R168, R170 83.32 KOHM 1% .25W MC1206 RESISTOR
435023
R23, R24, R31, R33, R65, R66, R88, R89, R99,
R102, R175
114.99 KOHM 1% .25W MC1206 RESISTOR
435025R96, R100 26.19 KOHM 1% .25W MC1206 RESISTOR
435028
R5, R19, R22, R25, R26, R43, R45, R47, R59, R61,
R63, R64, R67, R69, R75-R86, R91, R93
2810.0 KOHM 1% .25W MC1206 RESISTOR
435028
R95, R122, R125, R144, R145, R153, R154, R163,
R165, R167, R169, R171, R185, R186
1410.0 KOHM 1% .25W MC1206 RESISTOR
435028R191, 192 210.0 KOHM 1% .25W MC1206 RESISTOR
435032R158, R173, R187 315.0 KOHM 1% .25W MC1206 RESISTOR
435034R97, R101 220.0 KOHM 1% .25W MC1206 RESISTOR
435039
R1, R2, R29, R34, R35, R41, R71, R73, R117, R121,
R124, R127, R129, R146, R155, R159
1640.2 KOHM 1% .25W MC1206 RESISTOR
435039R172, R177-R184, R190, R193 1140.2 KOHM 1% .25W MC1206 RESISTOR
435043R176 188.7 KOHM 1% .25W MC1206 RESISTOR
500021CR1 110K TRIM POT
500029STUDIO/HDPN/CR POT 310K POT, DUAL AUDIO
510080TB SWITCH 1PUSHBUTTON SWITCH, 2 POLE MOMENTARY (LUGS)
510113SW2-SW7 52 POLE PUSHBUTTON SWITCH, MOMENTARY
510282SW1 17 POSITION RIGHT ANGLE DIP SWITCH
520038STUDIO/HDPN/CR KNOB 315mm GREY COLLET KNOB FOR 1/4" SHAFT
530045STUDIO/CR POT CAP 211mm BLUE CAP W/WHITE LINE FOR 15mm KNOB
530048TB SWITCH BUTTON 1 AMBER BUTTON
530080HDPN POT CAP 1CREAM CAP W. BLACK LINE FOR 15MM KNOB
530083EXT/PGM/AUD/MONO/PRE SWITCH BUTTON 5CUSTOM WHITE LIGHT PIPE BUTTON
605010DS1 1HIGH INTENSITY AMBER SMT LED RIGHT ANGLE
605017DS3 1ULTRABRIGHT RIGHT ANGLE RED SMT LED
605018DS4 1ULTRABRIGHT RIGHT ANGLE GREEN SMT LED
605019DS5, DS6 2ULTRABRIGHT RIGHT ANGLE YELLOW SMT LED
700649PCB_CR2000 1PRINTED CIRCUIT BOARD SMT
8200472D SUB STANDOFFJACK HARDWARE 3/16" LONG
8210094PEM FASTENERS
825010U20-U22 3HEATSINK FOR T-220 WITH MOUNTING PIN
835001F2-F4 3FUSE/ POLYSWITCH .3AMP SMT RESETABLE
page 10 - 7
R-55 / Mar 2003
