SPN-55 SUPERPHONE MODULE PARTS LIST
0055241FACEPLATE
220120CT1 1RIGHT ANGLE 25 PIN PC MOUNT CONNECTOR .318
23003126 PIN .098" PLUG FOR #26 AWG
23003219 PIN .098" PLUG FOR #26 AWG
250065CT6, CT7 26 PIN .098" HEADER
250066CT4 19 PIN .098" HEADER
305004U6 174ACT00 TTL SMT Quad 2-Input NAND
325001U1-U5 5NE5532 DUAL LINEAR OP-AMP SMT
345002Q1, Q2 2MMBTA55 PNP SMT TRANSISTOR
350013Z3 16.2V 1W ZENER DIODE
355001D5, D6 21N4002W RECTIFYING 1AMP SMT DIODE
355002Z1, Z2 25.1V SMT ZENER DIODE C5V1
355003D1-D4 41N4148 FAST SWITCHING SMT DIODE
385001U7-U11 574VHC4053 SMT Triple 2-Channel Analog Mux
405002C2, C3, C23, C27, C29-C31, C35, C37-C39, C44 12CAPACITOR, 22µF 25V ELECTROLYTIC SMT
405003C10, C22, C28 3CAPACITOR, 100µF 25V ELECTROLYTIC SMT
415001
C5, C6, C8, C11, C13-C15, C17, C19, C20, C24,
C26
12CAPACITOR, 10pF 100V CERAMIC SMT
415006C41 1CAPACITOR, .01µF 50V CERAMIC SMT
415007
C4, C7, C12, C16, C18, C21, C25, C32-C34, C36,
C40, C43, C45
14CAPACITOR, .1µF 50V CERAMIC SMT
415009C42 1CAPACITOR, .22µF 50V CERAMIC SMT
435002R2, R5, R6, R20, R39, R41 610 OHM 5% .25W MC1206 RESISTOR
435007R7, R8, R10, R13, R81, R82 6100 OHM 5% .25W MC1206 RESISTOR
435009R42, R52, R79 3220 OHM 5% .25W MC1206 RESISTOR
435015R80 11.00 KOHM 1% .25W MC1206 RESISTOR
435017R12, R26, R29, R30 41.69 KOHM 1% .25W MC1206 RESISTOR
435020R37, R38, R75-R78 62.43 KOHM 1% .25W MC1206 RESISTOR
435023R55, R62-R68, R73, R74 104.99 KOHM 1% .25W MC1206 RESISTOR
435026R11, R14, R28, R31 48.45 KOHM 1% .25W MC1206 RESISTOR
435028
R1, R21, R22, R24, R25, R36, R43, R45, R47, R49,
R51, R57, R58, R69-R72, R83
1810.0 KOHM 1% .25W MC1206 RESISTOR
435036R40, R54 222.1 KOHM 1% .25W MC1206 RESISTOR
435039R35 140.2 KOHM 1% .25W MC1206 RESISTOR
435041R15, R32 253.6 KOHM 1% .25W MC1206 RESISTOR
435043R34, R53 288.7 KOHM 1% .25W MC1206 RESISTOR
500021CR1 110K TRIM POT
510063ON/OFF SWITCH 2
DPDT PUSHBUTTON SWITCH, MOMENTARY ACTION,
GRAY HOUSING
510097SW2-SW6 52 POLE PUSHBUTTON SWITCH, ALTERNATE ACTION
