AudioArts Engineering R-55 - Chapter 10 - Parts List; Stereo Line Input

W#
ITEM#
QTYDESCRIPTION
SL-55 STEREO LINE INPUT MODULE PARTS LIST
005520SL-55 1FACEPLATE
220120CT1 1RIGHT ANGLE 25 PIN PC MOUNT CONNECTOR .318
23003126 PIN .098" PLUG FOR #26 AWG
23003219 PIN .098" PLUG FOR #26 AWG
250065CT5, CT6 26 PIN .098" HEADER
250066CT3 19 PIN .098" HEADER
305004U5 174ACT00 TTL SMT Quad 2-Input NAND
325003U1-U4 4TL072 DUAL LINEAR OP-AMP SMT
345002Q1, Q2 2MMBTA55 PNP SMT TRANSISTOR
350013Z3 16.2V 1W ZENER DIODE
355001D6, D7 21N4002W RECTIFYING 1AMP SMT DIODE
355002Z1, Z2 25.1V SMT ZENER DIODE C5V1
355003D1-D5, D8 61N4148 FAST SWITCHING SMT DIODE
385000U6-U10 54053 SMT
405002C1, C12, C24-C28, C33, C37, C39, C42 11CAPACITOR, 22µF 25V ELECTROLYTIC SMT
405003C2, C3, C11, C32, C40, C41 6CAPACITOR, 100µF 25V ELECTROLYTIC SMT
415001C5-C7, C9, C10, C14-C16, C18, C19, C21, C29 12CAPACITOR, 10pF 100V CERAMIC SMT
415006C44 1CAPACITOR, .01µF 50V CERAMIC SMT
415007
C4, C8, C13, C17, C20, C23, C30, C34-C36, C38,
C43, C46, C47
14CAPACITOR, .1µF 50V CERAMIC SMT
415009C45 1CAPACITOR, .22µF 50V CERAMIC SMT
435002R34, R36, R46 310 OHM 5% .25W MC1206 RESISTOR
435007R27, R80, R81 3100 OHM 5% .25W MC1206 RESISTOR
435009R26, R37, R50, R78 4220 OHM 5% .25W MC1206 RESISTOR
435010R41 1332 OHM 1% .25W 1206 RESISTOR SMT
435013R29, R39, R43, R45, R48 5619 OHM 1% .25W MC1206 RESISTOR
435015R30, R79 21.00 KOHM 1% .25W MC1206 RESISTOR
435020R32, R33, R70, R71, R76, R77 62.43 KOHM 1% .25W MC1206 RESISTOR
435021R56, R73, R75, R84 43.32 KOHM 1% .25W MC1206 RESISTOR
435023
R1, R3, R4, R7, R8, R14, R16, R17, R20, R21,
R57-R60
144.99 KOHM 1% .25W MC1206 RESISTOR
435028
R2, R5, R6, R9, R15, R18, R19, R22, R28, R31,
R38, R40, R42, R44, R47, R53, R61-R69, R72
2610.0 KOHM 1% .25W MC1206 RESISTOR
435028R74, R82, R83 310.0 KOHM 1% .25W MC1206 RESISTOR
435036R23, R35, R52 322.1 KOHM 1% .25W MC1206 RESISTOR
435039R54, R55 240.2 KOHM 1% .25W MC1206 RESISTOR
435043R24, R49 288.7 KOHM 1% .25W MC1206 RESISTOR
500078ACR1, CR2 2POT TRIM 100KBECKMAN 72XLR100K
510063START/STOP SWITCH 2
DPDT PUSHBUTTON SWITCH, MOMENTARY ACTION,
GRAY HOUSING
page 10 - 2
R-55 / Aug 2003
