Mediant 1000
Note: The CM module is applicable only to OSN1.
 iPMX module (housed in the rear panel):
Figure 5-2: iPMX Module (Only for OSN1)
Figure 5-3: iPMX Module (For OSN2)
 Hard Drive module (HDMX) (housed in the rear panel):
Figure 5-4: Hard Drive Module (HDMX)
