AudioCodes Mediant 1000 Installation Manual

Version 6.0 71 February 2010
Installation Manual 5. Open Solution Network (OSN) Server Platform
5.2.3 Installing Linux
Once you have cable the device as described in the previous section, you can install the
Linux OS.
¾ To install Linux on the OSN server:
1. Start a terminal application (e.g. HyperTerminal) on your PC, and create a new
connection with the following settings:
• Connect Port: COM1
• Baudrate: 115200 (bits per second)
• Data Bits: 8
• Parity: None
• Stop Bits: 1
• Flow Control: None
2. Power up the device.
3. Enable console installation from the system BIOS, by performing the following:
a. When the system starts, press the CTRL+C key; after several seconds, the
following BIOS setup window is displayed:
Figure 5-13: System BIOS Setup Window
b. Select the Features Configuration option.

AudioCodes Mediant 1000 Specifications

General

Data link protocols	CAS: MF-R1: T1 CAS, ISDN PRI: ETSI/EURO ISDN, ANSI NI2, QSIG
Security algorithms	HTTPS, SRTP
Authentication method	RADIUS
Internal memory	512 MB
Built-in processor	Celeron 600 MHz
Processor frequency	600 MHz
Internal memory type	-
Number of processors installed	1
Voice codecs	G.711, G.723.1, G.726, G.729A, iLBC
Safety	UL60950-1, FCC 47 CFR
Certification	ETS 300019-2-1, ETS 300019-2-2 ETS 300019-2-3
Mounting type	Rack mounting
LED indicators	Yes
Power requirements	90-260 V AC

Weight and Dimensions

Size (imperial)	19 \
