AudioCodes Mediant 500L MSBR - LED Descriptions; Power LED; Status LED; Table 3-2: Front Panel Description

Hardware Installation Manual 16 Document #: LTRT-10444
Mediant 500L MSBR
Table 3-2: Front Panel Description
Item # LED Label Description
1
Power
Indicates the status of the power supply to the device. For more
information, see Section 3.2.1 on page 16.
2
Status
Indicates the operating status of the device. For more information,
see Section 3.2.1.2 on page 16.
3
Wi-Fi
Indicates the operating status of the wireless LAN interface. . For
more information, see Section 3.2.1.3 on page 17.
Note: The LED is available only on models ordered with wireless
LAN functionality.
4
WAN GE
Indicates the status of the Gigabit Ethernet WAN connection. For
more information, see Section 3.2.1.4 on page 17.
5
WAN SFP
Indicates the status of the optical fiber WAN connection. For more
information, see Section 3.2.1.4.2 on page 17.
6
WAN A/VDSL
Indicates the status of the A/VDSL WAN connection. For more
information, see Section 3.2.1.4.3 on page 18.
3.2.1 LED Descriptions
3.2.1.1 Power LED
The Power LED indicates the operating status, as described in the table below.
Table 3-3: Power LED Description
LED
Color
LED
State
Description
Green
On Power is received by the device.
- Off No power is received by the device.
3.2.1.2 Status LED
The Status LED indicates the operating status, as described in the table below.
Table 3-4: Status LED Description
LED
Color
LED
State
Description
Green
On Device is operational.
Flashing Initial rebooting stage.
Red
On Boot failure.
-
Off Advanced rebooting stage.
