AudioCodes Mediant 500L MSBR Installation Manual

MSBR Series 17 Mediant 500L MSBR
Hardware Installation Manual 3. Physical Description
3.2.1.3 Wi-Fi LED
The Wi-Fi LED indicates the Wi-Fi link status, as described in the table below.
Table 3-5: Wi-Fi LED Description
LED Color LED State Description
Green
On Wi-Fi is activated.
Flashing Traffic on the wireless LAN.
-
Off Wi-Fi is not configured.
3.2.1.4 WAN LEDs
3.2.1.4.1 GE WAN LED
The WAN GE LED indicates the status of the Gigabit Ethernet (copper) WAN link, as
described in the table below.
Table 3-6: WAN GE LED Description
LED
Color
LED
State
Description
Green
On WAN GE link established.
Flashing Data is being received or transmitted.
-
Off No WAN GE link or power not received by the device.
3.2.1.4.2 SFP WAN LED
The WAN SFP LED indicates the status of the optical fiber WAN link, as described in the
table below.
Table 3-7: WAN SFP LED Description
LED
Color
LED
State
Description
Green
On WAN fiber link established.
Flashing Data is being received or transmitted.
-
Off No WAN fiber link or power not received by the device.
