AudioCodes Mediant 500L MSBR - LAN Interface Leds; Table 3-10: LAN LED Description

Hardware Installation Manual 20 Document #: LTRT-10444
Mediant 500L MSBR
Item # Label Description
sales representative.
7
FE LAN
Up to four Fast Ethernet (10/100Base-T) ports (RJ-45) for
connecting to LAN network such as IP phones, computers, and
switches. These ports support half- and full-duplex modes, auto-
negotiation, and straight or crossover cable detection.
8 Wi-Fi pinhole button for enabling and disabling Wi-Fi. Use a paper
clip or any other similar pointed object to press the button.
Note: The Wi-Fi button is available only for models ordered with the
Wi-Fi functionality.
9 FXS / FXO / BRI Telephony interfaces, depending on ordered configuration:
 Up to two ISDN BRI port interfaces (RJ-45)
 Up to four FXS port interfaces (RJ-11)
 Up to four FXO port interfaces (RJ-11)
10
-
Multiple-input and multiple-output (MIMO) 2Tx/2Rx antennas,
operating in the 2.4 GHz frequency range for wireless LAN
802.11n/b/g (Wi-Fi) access point functionality.
Note: The Wi-Fi antennas are applicable only to models ordered
with the Wi-Fi functionality.
3.3.1 LAN Interface LEDs
Each Ethernet port provides a LED for indicating LAN operating status, as described in the
table below.
Table 3-10: LAN LED Description
LED
Color
LED
State
Description
Green
On Ethernet link established.
Flashing Data is being received or transmitted.
-
Off No Ethernet link.
