Version 7.2 59 Mediant 1000B Gateway & E-SBC
User's Manual 6. Web-Based Management
Note: If you assign a non-mandatory parameter with a referenced row and then later
delete the referenced row (in the table in which the row is configured), the
parameter's value automatically changes to an empty field (i.e., no row assigned).
Therefore, make sure that you are aware of this and if necessary, assign a different
referenced row to the parameter. Only if the parameter is mandatory is the Invalid
Line icon displayed for the table in which the parameter is configured. For example,
if you delete a SIP Interface that you have assigned to a Proxy Set, the invalid icon
appears alongside the Proxy Sets item in the Navigation tree as well as on the Proxy
Sets page.
6.1.6.5 Viewing Table Rows
Tables display a certain number of rows per page. If you have configured more than this
number, you can use the table's navigation bar to scroll through the table pages, as shown
below and described in the subsequent table:
Table 6-3: Table Navigation Bar Description
Item # Description
1
Navigation buttons to view previous table rows:
 Displays the previous table page
 Displays the first table page (i.e., page with at least the first index row)
2
Navigation buttons to view the next table rows:
 Displays the next table page
 Displays the last table page (i.e., page with last index row)
3
Currently displayed table page. To open a specific table page, enter the page number
and then press the Enter key.
4
Total number of table pages.
6.1.6.6 Sorting Tables by Column
You can sort table rows by any column and in ascending order (e.g., 1, 2 and 3 / a, b, and
c) or descending order (e.g., 3, 2, and 1 / c, b, and a). By default, most tables are sorted by
the Index column and in ascending order.
