Version 6.0 41 March 2010
Installation Manual 3. Configuring the Device
3.1.4 Assigning an IP Address Using the CLI
You can assign an IP address to the device, using command-line interface (CLI).
Note:
The CLI method for assigning an IP address is not applicable to MP-112 as
this model does not provide RS-232 serial interface.
To assign an IP address via the CLI:
1. Connect the device's RS-232 port to either COM1 or COM2 communication port on
your PC (for MP-11x, refer to “Connecting the MP-11x RS-232 Port to Your PC” on
page 20; for MP-124, refer to “Connecting the MP-124 RS-232 Port to Your PC”
2. Use a serial communication software (e.g., HyperTerminal
on
page 31).
TM
•
) to establish a serial
communication link with the device, using the following communications port settings:
Baud Rate: 9,600
•
bps for MP-11x; 115,200 bps for MP-124
Data Bits:
•
8
Parity:
•
None
Stop Bits:
•
1
Flow Control:
The CLI prompt appears.
None
3. At the prompt, type conf
4. To view the current network parameters, at the prompt, type
, and then press <Enter>; the configuration folder is
accessed.
GCP IP
5. Change the network settings by typing the following:
, and then press
<Enter>; the current network settings are displayed.
SCP IP
For example,
[ip_address] [subnet_mask] [default_gateway]
SCP IP
The new settings take effect on-the-fly and connectivity to the device is active at the
new IP address.
10.13.77.7 255.255.0.0 10.13.0.1
Note:
6. To save the configuration, at the prompt, type
This command requires you to enter all three network parameters (each
separated by a space).
SAR
, and then press <Enter>; the device
restarts with the new network settings.
