Deployment Guide 2. RXV100 Components
Version N/A 19 RXV100
2.1.2.4 Signing out and Resetting the MTR Application
If you need to sign out from the current MTR account, perform a device reset. Resetting the
RXV100 is required to clear the MTR account credentials and peripheral settings.
This only
affects the Skype/MTR account. It doesn’t affect the Windows Operating System.
To reset the RXV100:
Click More and select the gear icon ; the Settings are displayed, select Reset
Device and then confirm.
2.2 RXVCam50M/L
The RXVCam50M is intended for small to medium rooms with a wide field of view (FOV).
The RXVCam50L is ideal for large meeting rooms with a narrow FOV.
2.2.1 Positioning and Connecting the RXVCam50M/L
To position and connect the RXVCam50M/L:
1. For the best viewing angle, position the device at a height of between 1.8 m and 2.1 m (6
ft to 7 ft) (as shown below left) within a radius of a 100/81-degree angle (as shown below
right).
