AudioControl LC-4.800 User Manual

7
Power Connections
In this example, the head unit has a +12V trigger
output that is connected to the LC-4.800’s remote
input terminal. When the head unit is turned on, it
will turn on the LC-4.800 amplier.
Alternatively, the GTO signal sense feature can be
used to gently turn on the LC-4.800 amplier when
an audio input signal is detected. In this case, the
connection to the LC-4.800’s remote input terminal
is not required.
Use 8 to 3 AWG insulated wire for the +12V and
Ground connections.
Ground
Head Unit
Remote Amplifier
+12V Trigger
+12V
