AudioControl LC-4.800 User Manual

9
System #2: Using line-level inputs
2-Channel
Audio Device
Line-level
Left Out
Right Out
Speaker-level output
30 to 80 Hz
and above
Speaker-level output
30 to 80 Hz
and above
Line
Level
EPICENTER 600 Subwoofer Amplifier
Optional
+
+
+
+
ACR-1
Subwoofer
+
Notes:
Both crossovers are set to
high-pass, and adjusted to
suit, depending on if you
have a subwoofer or not.
If the AccuBASS®/ACR-1
switches are set to “enabled”
the ACR-1 and AccuBASS®
aects all outputs.

AudioControl LC-4.800 Specifications

General

Brand	AudioControl
Model	LC-4.800
Category	Amplifier
Language	English
