Audiolab 8300A User Manual

Page 10
9: Specifications
Measurement made with 230V power supply
Pre-amplifier Section
Gain 0dB (Volume=0dB, Line/XLR)
+48dB (Phone MM, Volume=0dB)
+68dB (Phono MC,Volume=0dB)
Input Sensitivity 865mV (Line, Volume = 0dB)
1.7V (XLR, Volume = 0dB)
3.3mV (Phone MM, Volume=0dB)
330uV (Phono MC,Volume=0dB)
Input Impedance 50K (Line)
10K (XLR)
47K (Phono MM)
100R (Phono MC)
Output Voltage 3.0V max. (Volume = 0dB)
Output Impedance 120R
Signal-to-Noise Ration (S/N) > 107dB (Line/XLR)
>109dB (Line/XLR, A-Weighted)
>73dB (Phono MM), >78dB( Phono MM, A-Weighted)
>68dB (Phono MC), >73dB( Phono MC, A-Weighted)
Power Amplifier Section
Gain +29dB (@ 1KHz)
Rated Max. Power Output 2 X 75W (8 ohm, THD<1%)
2 X 115W (4 ohm, THD<1%)
Input Impedance 50K
Frequency Response +/- 0.2dB (10Hz ~ 20kHz)
-1.0dB (55kHz)
Input Sensitivity 865mV (Volume = 0dB)
Total Harmonic Distortion (THD) <0.003% (50W / 8ohm @ 1kHz)
Crosstalk <80dB (@ 10kHz)
Max. Power Consumption 440W
Standby Power Consumption <0.5W
Power Requirements 240V ~ 50 - 60Hz
230V ~ 50 - 60Hz
115V ~ 50 - 60Hz
100V ~ 50 - 60Hz
Dimensions (mm) (W x H x D) 444 x 80 x 330.3 - including feet, terminals and controls
Carton Size (mm) (W x H x D) 500 x 140 x 455
Weight 7.8kg (Net)
9.0kg (Gross)

Audiolab 8300A Specifications

General

Built-in display	Yes
Line inputs (RCA)	1
Line outputs (RCA)	2
Speakers connectivity type	Binding post
Damping factor	100
Output impedance	120 Ω
Input sensitivity	840 mV
Signal-to-Noise Ratio (SNR)	107 dB
Total Harmonic Distortion (THD)	0.002 %
Purpose	-
Product color	Silver
Connectivity technology	Wired

Weight and Dimensions

Depth	330.3 mm
Width	444 mm
Height	80 mm
Weight	7800 g
