ADVANCED MANUAL / bit Ten D /
11
5.5 LOW-LEVEL INPUT SIGNALS
AUX IN L/R: Auxiliary analog stereo signal.
Sensitivity is adjustable from 0.6 to 5 V RMS.
5.6 OPTICAL IN DIGITAL INPUT
Digital Input- Warning: the digital inputs accepts up to 96 kHz / 24 bit stereo PCM signals. So DOLBY DIGITAL (AC3)
multi-channel signals coming from audio/video sources (such as the audio of a film in DVD) or DTS can not be
reproduced. The output of these devices will therefore be set in STEREO mode for the signal to be reproduced.
If digital signals at frequency higher than 96kHz (Ex. 192 kHz) are supplied, the bit Ten D locks up.
AD Link
AC Link
Optical fiber
TOSLINK
connector
PCM stereo signal, max 96 kHz/24bit
5
AUXILIARY STEREO
PREAMPLIFIER SOURCE
AUXILIARY STEREO
PREAMPLIFIER SOURCE
AD Link
AC Link
AD Link
AC Link
MP3 PLAYER
PRE OUT
RADIO DECK
