76
LRx 4.5
LRx 4.1k
75
The Universal Sound
How to use pre-drilled cards
Below you can find some examples of the most popular system configurations on the
supplied pre-drilled cards. If you lay them onto the control panel, you will be able to adjust
the controls for maximum performance according to the chosen configuration.
Choose the system
configuration you like
and lay the
corresponding
card onto the
control panel.
Carry out the adjustments according to
the instructions on the card.
Remove the card and
the amplifier is ready
to be used.
Example: Active 2 way system, Tweeter + Woofer, 4 channel mode,
A channel input driven
Owner’s manual
