Fault / NAMUR failure
RemedyDescription/causeDisplay (App or CDT)
Use AUMA Assistant App or AUMA CDT to visualise
the individual signals by means of the Diagnostics
menu.
Check the configuration parameters for the sub-as-
sembly.
In case the problem persists: Contact AUMA Ser-
vice.
Collective signal 22:
Configuration error has occurred.
The fieldbus or I/O board fails either due to incor-
rectly set configuration parameters or caused by
defective hardware
Configuration error REMOTE
Check configuration.
IE remote parameter configuration
Check configuration.
IE fieldbus
Contact AUMA service.Collective signal 28:
Hardware or software faults of motor or motor con-
trols
Fault motor controls
Contact AUMA service.
Motor shutdown
Contact AUMA service.
Motor overvoltage
Contact AUMA service.
Motor overcurrent
Contact AUMA service.
Motor overtemp.
Contact AUMA service.
MotCtrl Fault control
Table 23:
Warning / NAMUR out of specification
RemedyDescription/causeDisplay (App or CDT)
Use AUMA Assistant App or AUMA CDT to visualise
the individual signals by means of the Diagnostics
menu.
Collective signal 15:
Device warnings.
The device can still be operated with restrictions.
Internal warning
Check 24 V DC inputs (DIN).Part of collective signal 15:
The 24 V DC customer auxiliary supply (to control
the digital inputs) has failed.
24 V DC customer
Check internal 24 V DC voltage supply.Part of collective signal 15:
The internal 24 V DC supply voltage of the controls
for supply of the electronic components is outside
the supply voltage limits.
24 V DC internal
Use AUMA Assistant App or AUMA CDT to visualise
the individual signals by means of the Diagnostics
menu.
Collective signal 06:
Faulty configuration.
The device can still be operated with restrictions.
Configuration warning
Configure analogue inputs AIN 1 or AIN 2.
Wrn Setpoint Source
Check positioner setting.
Wrn dead bands
Check fieldbus interface configuration.
Wrn Fieldbus configuration
Verify torque switching setting.
Torque configuration CLOSE
Verify torque switching setting.
Torque configuration OPEN
Check EMERGENCY configuration.
Configuration EMERGENCY
Check configuration of reaction monitoring.
Configuration reaction monitoring
●
Check modulating behaviour of actuator.
●
Check parameter PRM_2122 Permissible run
time, set again if required.
Warning on time max. running time/h exceeded.
Wrn operation mode run time
●
Check modulating behaviour of actuator.
●
Check parameter PRM_2123 Permissible starts,
set again if required.
Warning on time max. number of motor starts
(starts) exceeded.
Wrn operation mode starts
Check signals:
●
Setpoint E1
●
Actual value E2
●
Actual process value E4
●
Check connection to master.
●
For Profibus or Profinet: Check (clear) status of
master.
The failure behaviour is active since all required
setpoints and actual values are incorrect.
Failure behaviour active
Check wiring.Warning: Loss of signal analogue input 1
Wrn input AIN 1
44
PF-Q80 – PF-Q600
Corrective actions
