AUTEC - Air series
Operation 19
LILK1E00-01
7.3.5 BACK-UP UNIT
If the main transmitting unit cannot be used because it has been lost or damaged, it can be
replaced with a transmitting unit called "BACK-UP UNIT".
Itisidenticaltotheunitthatcannotbeusedanymore;theonlydierenceisthepresenceof
the plate “BACK-UP UNIT” on the battery housing.
Set DIP switch 2 in the "BACK-UP UNIT" as shown in the technical data sheet.
If the transmitting unit that can no more be used requires either a "Key ID
0-1" or an "ID internal tx memory" (see technical data sheet), move it to the
"BACK-UP UNIT" and perform the address saving procedure described below.
If the transmitting unit that can no more be used does not require either a
"Key ID 0-1" or an "ID internal tx memory" (see technical data sheet), perform
the PAIR procedure to pair the “BACK-UP UNIT” with a receiving unit (the
technical data sheet shows which PAIR procedure to use).
Address storage
With fully charged battery and power keyswitch in the "BACK-UP UNIT", perform this procedure:
1. press the START pushbutton until the green and red LEDs light up.
2. wait until the green LED blinks slowly
3. within 3 seconds, activate in sequence the commands corresponding to PIN 1, PIN 2 and
PIN 3 that compose the PIN code given in the technical data sheet.
IfthePINcodeisincorrect,theredLEDilluminatesandthetransmittingunitswitcheso.In
this case, the storage procedure shall be repeated.
If the PIN code is correct, the green LED turns steady on and the transmitting units switches
o:thisindicatesthattheaddresshasbeenstoredinthe"BACK-UPUNIT".Itisnow
possible to start the radio remote control and control the machine with the "BACK-UP UNIT"
transmitting unit.
