8.11 Starting up the Radio Remote Control
Starting up the Radio Remote Control consists in establishing a radio link between the
Transmitting Unit and the Receiving Unit.
The Radio Remote Control start up is protected by means of a power
keyswitch and/or a PIN code to prevent unauthorised use of the Machine.
To start up the Radio Remote Control, you need to insert the power keyswitch
and\or to key in the PIN code according to the procedure provided in
paragraph 8.11.1,8.11.2 or 8.11.3.
The PIN code is not a sequence of numbers, but it consists in the sequential activation of
actuators.
Commands associated to the actuators that are activated while inserting the PIN
code are not sent to the Machine.
If the Transmitting Unit does not have a power keyswitch, the Radio Remote Control start
up is protected by PIN code.
On the contrary, when the Transmitting Unit needs a power keyswitch, Radio Remote Control
start up is protected by the power keyswitch itself. If the risk assessment requires further
protection of the Radio Remote Control start up, the PIN code can be activated too.
8.11.1 power keyswitch start up (no PIN code)
When the Receiving Unit is powered on correctly, perform the following procedure:
1. Insert a charged battery in the Transmitting Unit (see paragraph 8.7.1),
2. insert the power keyswitch in the Transmitting Unit (see paragraph 8.1.3),
3. press the "Enabling&Stop" pushbutton halfway (ON - rst step, see paragraph 8.6),
4. press the START pushbutton and hold it down until the green LED blinks quickly.
5. release the START pushbutton.
When the green LED blinks slowly, the Radio Remote Control is active and it can send
commands and activate the Machine.
AUTEC - Air series
General operating instructions 35
LIULK1ES0_eng-01
