8.6 "Enabling&Stop" pushbutton
A three-position pushbutton, called "Enabling&Stop", is present on the left side of the
Transmitting Unit.
A
A
A "Enabling&Stop" pushbutton
The "Enabling&Stop" pushbutton is used to perform two functions:
a. Enabling function: if it is activated at the same time as other actuators, it enables sending
the corresponding commands to the Machine;
b. Stop function: if it is released or completely pressed, it switches o the Transmitting Unit
and stops the Radio Remote Control.
These are the three possible positions for the "Enabling&Stop" pushbutton:
1. not pressed (OFF - rest position): the release of the "Enabling&Stop" pushbutton stops
the Radio Remote Control;
2. halfway pressed (ON - rst step): the "Enabling&Stop" pushbutton enables the operation
of the other actuators in the Radio Remote Control;
3. completely pressed (OFF - second step): the "Enabling&Stop" pushbutton disables the
operation of the other actuators while also stopping the Radio Remote Control.
The Radio Remote Control can start only if the "Enabling&Stop" pushbutton is in the halfway
position (position “2”; see paragraph 8.11)
When you release the "Enabling&Stop" pushbutton from position "3", you will skip position
"2" and go directly to position "1".
To start the Radio Remote Control again and enable it to control the Machine after the
"Enabling&Stop" pushbutton has activated the stop, you need to:
- make sure that the working and usage conditions are safe,
- start the Radio Remote Control following the procedure described in paragraph 8.11.
AUTEC - Air series
General operating instructions 29
LIULK1ES0_eng-01
